BELT
THICKENER ZZ
1000(THICKENING
OF TREATED SLUDGE AND SUSPENSIONS) |
| BELT
PRESSES
KCZ |
800/S |
|
800 |
|
1000 |
|
KC |
1500 |
|
2000 |
|
 |
 |
| TYPE |
KCZ
800/S |
KCZ
800 |
KCZ
1000 |
KC
1500 |
KC
2000 |
ZZ
1000 |
| OUTPUT
(m3 per hour) |
2
* |
4
- b * |
6
-10 * |
8
-13 |
13
- 20 |
15
- 20 |
| DRY
SOLID (%) |
18
- 30 |
20
- 40 |
20
- 40 |
20
- 30 |
20
- 30 |
6
-15 |
| POWER
INPUT (kW) |
0,75 |
0,75 |
1,50 |
3
(+0,55) ** |
3
(+0,55) ** |
0,75 |
| VOLTAGE
(V) |
250 |
400 |
400 |
400 |
400 |
400 |
| WEIGHT
(t) |
0,9
|
2,4
|
2,9 |
6,5 |
7,8
|
0,7
|
| DIMENSIONS
(mm) |
|
|
|
|
|
|
| HEIGHT |
1500 |
2300 |
2300 |
2900 |
2900 |
1112 |
| LENGTH |
3400 |
3950 |
4050 |
4600 |
4600 |
2200 |
| WIDTH |
1550
|
1600 |
1800 |
2972 |
3300 |
1600 |
| SIEVE
MOVEMENT SPEED (m pers) |
0,02
- 0,2 |
0,02
- 0,12 |
0,02
- 0,12 |
0,02
- 0,12 |
0,02
- 0,12 |
0,02
- 0,2 |
SPRAYING
WATER CONSUMPTION
(m3 per hour) |
3
- 9 |
1,9
- 6,l |
2,3
- 7,7 |
3,5
-12 |
5
-12 |
2 |
| AIR
CONSUMPTION (m3 per hour) |
-
|
3 |
3 |
5 |
5 |
1,5 |
*
MINERÁL SLUDGE, PAPER SLUDGE, SLUDGE WITH A SMALL ORGANIC PORTION
- OUTPUT BY 30 - 50 % HIGHER ** POWER INPUT OF THE MIXING DRUM
|
|
